Description
Maximum productivity
• Finish jobs faster with cut speeds two and a half times greater than
oxyfuel on 12 mm (1/2″) mild steel.
• Spend less time on grinding and edge preparation due to superior
cut and gouge quality.
Easy-to-use for cutting and gouging
• No need to change the air pressure. Smart Sense™ technology
ensures that it is always correctly set.
• Drag cut at full output with a patented shield that reduces dross
buildup for smoother cutting.
• Tackle different jobs with multiple, easy-to-use torch styles.
Low operating costs
• Reduce costs with long consumable life and more uptime.
• High power efficiency lowers energy consumption.
Built and tested to withstand the harshest conditions
• Duramax® torches are designed for high-impact and heat resistance.
• SpringStart™ technology ensures consistent starting and a more
reliable torch.
• Low maintenance for maximum uptime
Specifications
Input voltages = 200–480 V, 1-PH, 50/60 Hz / 200–600 V, 3-PH, 50/60 Hz
Kilowatt output = 12,2 kW
Input current @ 12,2 kW =
200/208/240/480 V, 1-PH 70/68/58/29 A
200/208/240/480/600 V, 3-PH 42/40/35/18/17 A
Output current = 25–85 A
Rated output voltage = 143 VDC
Duty cycle @ 40° C (104° F) =
60% @ 85 A, 230–600 V, 3-PH
60% @ 85 A, 480 V, 1-PH
50% @ 85 A 240 V, 1-PH
50% @ 85 A, 200–208 V, 3-PH
40% @ 85 A, 200–208 V, 1-PH
100% @ 66 A, 230–600 V, 1/3-PH
Open circuit voltage (OCV) = 305 VDC
Dimensions with handles = 500 mm D; 234 mm W; 455 mm H (19.7″ D; 9.2″ W; 17.9″ H)
Weight w/7,6 m (25′) torch = 32 kg (71 lbs.)
Gas supply = Clean, dry, oil-free air or nitrogen
Recommended gas inletflow rate/pressure =
Cutting: 189 l/min @ 5,9 bar (400 scfh, 6,7 scfm @ 85 psi)
Gouging: 212 l/min @ 4,8 bar (450 scfh, 7,5 scfm @ 70 psi)
Input power cable length = 3 m (10′)
Power supply type = Inverter – IGBT
Engine drive requirement = 20 kW for full 85 A output
Certifications = CSA-certified for use in the Americas and Asia, except China.
Warranty = Power supplies have a 3-year warranty and torches a 1-year warranty
