Description
The JASIC MIG 350 Separate equipped with powerful IGBT components, digital meters and multi process capabilities offers excellent welding characteristics and rugged, reliable performance. This high quality three phase inverter delivers an impressive 350 amps at 40% duty cycle, making the MIG 350 an excellent choice for medium to heavy duty industrial manufacturers. Featuring a unique (welding dynamic characteristic control circuit) in MIG, provides a stable arc, low spatter, excellent weld appearance and high welding efficiency.
Key Features
• IGBT MIG/MAG MMA inverter
• Digital amp & voltmeter
• High duty cycle
• 4 roll wire feed unit
• Advanced control circuitry
• Suitable for 0.8, 1.0 and 1.2mm
welding wire
• Burn back control & wire inching
• 2T/4T trigger function
• Power & status LED’s
• Gas check function
• Variable inductance
• Inverter trolley takes full size gas bottle
Technical Data
Input Voltage = AC 400V – 50/60 Hz
Ieff (A) = 13.2
Input Power (kVA) = 15
Voltage Adjustment Range (V) = 15 – 36
Current Range (A) = MIG 50-350 / MMA 20-350
Duty Cycle @ 40°C = 350A @ 40%
No-Load Voltage (V) = 65
Wire Speed (m/min) = 1 – 16
Efficiency (%) = 85
Power Factor = 0.93
Protection/Insulation Class = IP21S/F
