Description
Key Features
• IGBT inverter technology
• Wide input voltage 95-265V
• Anti-stick, Arc-force, Hot start, Lift TIG
• 33Khz inverter frequency, high-efficiency
• Compact size, lightweight and modern design
• Heavy duty 35-50mm dinse sockets
• Easy arc starting, minimal spatter
• Auto-compensation for voltage fluctuation
• High quality tactile rubber finish to mouldings and handle
• Supplied in full colour packaging
• Can weld electrodes of up to 4mm
• Digital setting meter
• Generator friendly**
Technical Data
Input Voltage = 95-265V – AC 50/60Hz 115V / 230V
Ieff (A) = 12.7 13.4
Input Power (kVA) = 3.5 7.2
Current Range (A) = 10 – 110 10 – 200
Duty Cycle @ 40°C = MMA 110A @ 25% 200A @ 25%
Duty Cycle @ 40°C = TIG 110A @ 35% 200A @ 40%
No-Load Voltage (V) = 68
Efficiency (%) = 85
Power Factor = 0.998
Protection/Insulation Class = IP21S/F
