Description
Key Features
• Industrial grade IGBT inverter technology
• DC Pulse TIG/MMA with VRD function option
• MCU chip for high accuracy and consistency
• HF or Lift arc ignition, 2T/4T, spot-time
• Up/down slope, pre/post flow, crater/initial/weld current
• Digital panel with interface for easy software upgrades
• Gas test function in DC TIG mode
• Automatic 8 channel storage of welding parameters
• On demand fan and water cooling
• Generator friendly**
Technical Data
Input Voltage = AC 400V – 50/60 Hz
Ieff (A) = 14
Input Power (kVA) = 18
Current Range (A) = TIG DC 5-400 / MMA DC 30-400
Duty Cycle @ 40°C = 400A @ 50%
No-Load Voltage (V) = 68
Efficiency (%) = 85
Power Factor = 0.96
Protection/Insulation Class = IP21S/F
